One suppressor, multiple pistols. That is the whole point of a swappable piston system, and this Yankee Hill Machine Sidewinder piston in 14.5x1mm LH is how you get your .40 S&W can onto a metric left-hand threaded barrel. The 14.5×1 LH pattern shows up most often on HK USP Tactical pistols in .40, so if that is what lives in your safe, this is the piston that bridges the gap between your barrel and your Sidewinder.
YHM machines this piston from heat treated 17-4 PH stainless steel, the same material used for the Sidewinder's adapter, Nielsen sleeve, blast baffle, and rear cap. That grade of stainless shrugs off corrosion and holds up to the heat and carbon abuse that comes with suppressed pistol shooting. It measures 1.950 inches long and weighs a scant 1.5 ounces, so it adds next to nothing to the front of your gun. Like everything else YHM turns out of its Massachusetts shop, it is made in the USA.
The Sidewinder was designed from the start to be user serviceable, and that extends to the booster assembly. Pull the rear cap, swap in this piston, and you are back on the range with a different host. No gunsmith visit, no special fixtures. It is a smart way to stretch the value of one tax stamp across several pistols instead of buying a dedicated can for each thread pattern.
One quick note on fitment: this piston is built for the Sidewinder's original Nielsen assembly, so double check that your setup matches before ordering. If you run a tilting-barrel or browning-action .40 with metric LH threads, keeping a spare piston on hand is also cheap insurance, since pistons are wear parts that take the brunt of every cycle. Whether you are adding a host or just replacing a well-used part, this is the exact piece YHM specs for the job.
The 14.5x1mm left-hand metric thread is most commonly found on HK USP Tactical barrels in .40 S&W, along with some aftermarket threaded barrels that follow the same European pattern. Check the thread spec stamped or listed for your barrel before ordering. If your barrel is 9/16×24, YHM makes the same piston in that pitch instead.
Yes. The Sidewinder is a user-serviceable suppressor, so the booster assembly comes apart without gunsmith help. Remove the rear cap, swap the piston into the Nielsen device, and reassemble. It takes a few minutes once you have done it a time or two.
This piston is made specifically for the Sidewinder's original Nielsen assembly. YHM notes it does not fit the YHM-2055 1.375-24 Nielsen booster, so verify which booster your can uses before you buy. If you are unsure, the part number on your booster housing will tell you what you have.
The piston takes a beating from hot gas, carbon, and constant cycling every time the gun fires. Heat treated 17-4 PH stainless resists wear, corrosion, and high temperatures far better than standard steels, which is why YHM uses it for the Sidewinder's piston, blast baffle, and rear cap. It keeps the part running reliably over thousands of rounds.
| UPC | 816701019087 |
|---|---|
| Manufacturer | |
| Manufacturer Part Number | YHM-3235-M |
| Package Width | 3.004 |
| Shipping Weight | 0.1 |
| Product Type | Accessory-Silencer Accessories |
| Package Height | 1.2 |
| Caliber/Gauge | .40 S&W |
