Sig Sauer ECHO MV35 Thermal Monocular 2-16x35mm 640×512

Description

The Sig Sauer ECHO MV35 is a compact thermal monocular engineered for observation, navigation, and wildlife monitoring in low-light conditions. It uses an LWIR thermal core with a 640×512 VGA sensor and a 12 micron pitch running at 50 Hz to deliver clear thermal imagery. The unit offers 2–16x digital magnification, BDX 2.0 mobile connectivity, and on-board photo and video recording with audio. Power is managed via an internal reserve cell plus a removable 18500 lithium-ion battery for extended operating time.

Key Specifications

• The thermal core is LWIR 640×512 VGA, 12 µm, 50 Hz.
• Magnification is 2–16x digital zoom.
• The objective lens is 35 mm.
• Runtime is 10 hours using internal reserve plus external 18500 battery.
• The unit can record photos and video with audio.
• Connectivity is BDX 2.0 enabled for mobile integration.
• Includes two 18500 rechargeable lithium-ion batteries in the shipping package.
• Weight without battery is 19 oz.
• Overall length is 7.0 inches.
• Ingress protection rating is IP67.

Compact, rugged, and feature-rich, the ECHO MV35 provides sustained runtime, clear thermal imaging, and mobile connectivity in a small package. Its recording capabilities, selectable palettes, and BDX compatibility make it a practical tool for observation, nighttime navigation, and wildlife study where reliable thermal performance and portability are priorities.
