Description
Magpul took everything folks liked about their original bipod and put it on a diet. The MOE Bipod runs on injection-molded polymer legs that shave off close to 40 percent of the weight compared to some of their earlier designs, landing at right around 8 ounces total. That kind of weight savings matters when you're carrying a rifle over rough ground all day or trying to keep a lightweight build from turning nose-heavy.
What Makes the MOE Bipod Tick
Setup is about as simple as it gets. A large ergonomic thumbwheel and self-locating stainless-steel clasps snug the bipod onto a standard Uncle Mike's-style sling swivel stud, and the non-marring over-molded saddle spreads the load across the forend without chewing up your stock finish. There are no buttons or levers to fumble with when deploying the legs. They stow forward out of the way, then snap down and lock into place with a firm pull. Folded up, the whole thing sits at a low 1.73-inch stack height, so it stays tucked in until you need it.
Dialing In the MOE Bipod Legs
The legs slide out from 7 to 10 inches and lock across seven half-inch spaced detents with the push of a button, giving you room to adjust for terrain or shooting position. Staggered soft rubber feet grip well on dirt, rock, benches, and just about anything else you'll set up on. If you want to run something different, the feet pop off with a roll pin punch and the legs accept most Atlas-pattern replacement feet.
Where the MOE Bipod Earns Its Keep
This one shines on hunting rifles and lighter builds where every ounce counts. It's a fixed platform without pan or tilt, which keeps things simple and rugged, and the legs lock in solid once deployed. There's also an optional low-profile sling stud spot on the rear of the mount, so you don't lose your sling attachment point by adding the bipod. Made in the USA.
Key Specifications
- Manufacturer: Magpul Industries
- Model: MOE Bipod
- Manufacturer Part Number: MAG1174-BLK
- UPC: 840815137894
- Color: Black
- Product Type: Bipod
- Construction: Injection-molded polymer with stainless-steel clasps
- Weight: Approx. 8 oz
- Height Adjustment: 7 to 10 in, half-inch increments
- Detent Positions: 7 locking detents per leg
- Folded Stack Height: 1.73 in
- Mount Type: Uncle Mike's-style sling swivel stud
- Feet: Removable rubber, Atlas-pattern compatible
- Country of Origin: Made in USA
What’s Included
- Magpul MOE Bipod (Black)
- Installed rubber feet
- Instruction sheet
Frequently Asked Questions
How does the Magpul MOE Bipod attach to a rifle?
It mounts to a standard Uncle Mike's-style sling swivel stud using a rapid-attach system. Self-locating stainless-steel clasps line everything up, then you snug it down with the large thumbwheel by hand. No extra tools or hardware needed, and it comes off just as quickly.
Can I put the MOE Bipod on an M-LOK handguard?
Not directly, since this model is built for a sling swivel stud. Magpul offers a separate MOE Bipod Adapter that adds a stud to an M-LOK or Picatinny handguard, which lets you run this bipod on rifles that don't have a factory stud.
Does the MOE Bipod pan or tilt?
No, this is a fixed platform without pan or tilt. That keeps the design simple, light, and rugged, and the legs lock in solid once deployed. If you need cant adjustment for uneven ground or tracking moving targets, a pan-and-tilt bipod would suit you better.
Can I swap the feet on the Magpul MOE Bipod?
Yes. The rubber feet are held on with roll pins and drift out easily with a roll pin punch. The legs accept most Atlas-pattern replacement feet, so you can set it up with spiked, skid, or claw feet depending on your terrain.
