YHM Sidewinder Direct Thread Adapter 1/2-28 Black – YHM-3251

UPC: 816701019667

$34.75

Out of stock

Online inventory may differ from in-store availability.

Fast Shipping

Quick turnaround so you get your gear sooner.

Secure FFL-Friendly Checkout

Trusted checkout with industry-standard protection.

Family-Owned Business

Keeping Traditions Alive Since 1953

Secure Transactions provided with

Description

If you run a Yankee Hill Sidewinder on a pistol, you already know the booster assembly is doing important work cycling that tilting barrel. But put that same can on a fixed barrel host, like a 9mm carbine or a braced PCC, and the piston setup becomes unnecessary weight and movement you just don't need. That's exactly what the YHM-3251 solves. Pull the spring retainer, spring, and piston out of your suppressor, thread this adapter in their place, and you've got a solid, fixed 1/2-28 direct thread mount ready for rifle duty.

Why the Sidewinder Direct Thread Adapter Earns a Spot in Your Range Bag

Yankee Hill machines this adapter from 17-4 PH stainless steel with a matte black finish, so it holds up to heat, carbon, and solvent without complaint. At three quarters of an inch long and just 1.86 ounces, it keeps your setup compact and doesn't add meaningful weight to the front of the gun. The threading is clean and precise, which matters when you're counting on repeatable alignment every time you spin the can on. Compatibility covers the Sidewinder, Sidewinder M2, Cobra, and Cobra M2 suppressors, so one adapter serves whichever of those cans you own.

Installing the YHM-3251 Direct Thread Mount

Installation is about as simple as it gets. Unscrew the rear cap components, remove the booster parts, and thread the adapter into the back of the suppressor. No gunsmith, no special tooling beyond what you'd normally use for suppressor maintenance. The 1/2-28 thread pattern covers a huge range of hosts, from 9mm carbines with 1/2-28 muzzles to .22 rifles and pistols, making this one of the most versatile mounting options in the Sidewinder lineup. If you split time between a threaded pistol and a fixed barrel long gun, keeping one of these on hand means your suppressor moves between both without a second thought. It's a small, American-made part that meaningfully expands what your can is capable of.

Key Specifications

  • Manufacturer: Yankee Hill Machine
  • Model: Sidewinder Direct Thread Adapter
  • Manufacturer Part Number: YHM-3251
  • UPC: 816701019667
  • Thread Pitch: 1/2-28
  • Material: 17-4 PH Stainless Steel
  • Finish: Matte Black
  • Length: 3/4 in
  • Weight: 1.86 oz
  • Compatibility: YHM Sidewinder, Sidewinder M2, Cobra, Cobra M2 suppressors
  • Product Type: Suppressor Mount / Direct Thread Adapter
  • Country of Origin: USA

What’s Included

  • Sidewinder Direct Thread Adapter, 1/2-28 (YHM-3251)

Frequently Asked Questions

Which suppressors does the YHM Sidewinder Direct Thread Adapter fit?

This adapter is made for Yankee Hill Machine's pistol caliber suppressor family, including the Sidewinder, Sidewinder M2, Cobra, and Cobra M2. It replaces the booster components inside the can, converting it to a fixed direct thread mount. It is not designed for suppressors from other manufacturers.

How do I install the Sidewinder Direct Thread Adapter?

Remove the spring retainer, spring, and piston from the rear of your suppressor, then thread the adapter into their place. It takes just a few minutes with basic suppressor maintenance tools. Once installed, the can threads directly onto any 1/2-28 muzzle.

Why would I use a direct thread adapter instead of the piston on my Sidewinder?

Boosters exist to help tilting barrel pistols cycle reliably with the added weight of a suppressor. Fixed barrel hosts like pistol caliber carbines and rimfire rifles don't need that assist, so a direct thread mount gives you a simpler, more solid connection with fewer moving parts. It also trims a bit of weight and keeps the can locked up consistently.

Will the 1/2-28 version work on my 9mm carbine?

As long as your barrel is threaded 1/2-28, yes. That pitch is common on many 9mm carbines and most .22 rimfire hosts. If your barrel is threaded 1/2-36 or M18x1, YHM offers this same adapter in those patterns under different part numbers, so double check your muzzle threads before ordering.

Additional information

UPC

816701019667

Manufacturer

Manufacturer Part Number

YHM-3251

Color

Black

Length

5.6500

Model

Product Type

Mount
