This is Redding's .362 diameter Titanium Nitride neck sizing bushing, the piece that lets you control exactly how much grip your case neck puts on a bullet. Instead of a one-size die that works the brass more than it needs to, you pick the bushing that matches your loaded neck diameter and size only what's necessary. The TiN version starts as the same heat treated, hand polished steel bushing and adds a titanium nitride surface treatment on top, which bumps up the effective surface hardness and cuts down on sizing friction. Less drag on the brass means smoother strokes and necks that stay consistent round after round.
Neck tension is one of those details that separates good handloads from great ones. By matching your bushing to the job, you hold the bullet with just the right press fit without overworking the neck, which is easier on your brass and friendlier to your groups. These bushings carry a hand polished sizing surface at a hardness of Rc 60-62, and the titanium nitride coating adds that extra slickness precision reloaders chase.
Every Redding neck bushing shares the same external footprint, 1/2 inch O.D. by 3/8 inch long, so they freely interchange across all Redding bushing-style neck sizing dies like the Type S line. The full TiN range runs from .185 through .368 in .001 inch increments, and each one is clearly stamped with its size I.D. so you always know what's loaded in the die.
To land on the correct bushing, measure the outside neck diameter of a loaded or dummy round with a micrometer, then subtract about .001 to .002 inch to account for brass spring-back and proper bullet tension. A lot of experienced reloaders also like to run the bushing numbers-down and size only part of the neck, which tends to help accuracy. If you already know this .362 is the number you need, it's a straightforward drop-in upgrade for your setup.
It fits any Redding bushing-style neck sizing die, including the Type S series. Every Redding neck bushing uses the same 1/2 inch O.D. by 3/8 inch long external size, so they interchange freely across those dies. You just drop in whichever diameter you need for the job.
Measure the outside neck diameter of a loaded or dummy round with a micrometer, then subtract about .001 to .002 inch to allow for brass spring-back and bullet tension. The result is the bushing size you want. If that math lands near .362, this is your bushing, though it's worth measuring your own brass since neck thickness varies.
Both start as the same heat treated, hand polished steel bushing with an Rc 60-62 surface hardness. The titanium nitride version adds a TiN surface treatment that further increases the effective hardness and reduces sizing friction. That slicker surface makes for smoother sizing strokes and can be a bit easier on your case necks.
A light touch of neck lube helps the sizing stroke run smoother even with the slick TiN coating. Many reloaders also install the bushing with the numbers facing down and size only part of the neck, which tends to help accuracy. It's a small step that keeps things consistent from one case to the next.
| UPC | 611760763625 |
|---|---|
| Manufacturer | |
| Manufacturer Part Number | 76362 |
