Description
Dialing in neck tension is one of those little details that separates good handloads from great ones, and this .326 bushing gives you that control. It's machined from heat-treated steel and hand polished to a surface hardness of Rc 60-62, then finished with a titanium nitride (TiN) coating that boosts the effective surface hardness even further and cuts down on sizing friction. The result is an easier stroke on the press and less stress on your case necks over repeated firings.
How the .326 Redding Bushing Fits Into Your Setup
This bushing freely interchanges across all Redding bushing-style sizing dies, including the popular Type S Full Length and Type S Neck dies as well as the Competition series. The bushings themselves measure a standard 1/2 inch outside diameter by 3/8 inch long, so they swap in and out in seconds. Each one is marked with its size for quick identification when you're reaching into a storage box full of them. Keep in mind bushings are sold separately from the dies, so this is the piece you add once you know exactly what neck diameter you need.
Picking the Right .326 Neck Sizing Bushing
The .326 refers to the inside sizing diameter. To find your correct size, measure the outside neck diameter of a loaded or dummy cartridge with a precision micrometer, then subtract .001 to .002 inches to account for brass spring-back and proper bullet tension. Redding offers these bushings in .001 inch increments covering calibers from .17 all the way up to .338, so you can fine-tune tension exactly how you want it.
Why the Titanium Nitride Version
Reloaders who run a lot of brass tend to favor the TiN bushings because the coating is slicker and takes noticeably less effort to size, and it's far less likely to scratch or mar case necks over time. The steel versions work fine too, but if you're chasing consistency and longevity, the titanium nitride finish is the one worth having. A light touch of neck lube still helps things run smooth. Made in the USA.
Key Specifications
- Manufacturer: Redding
- Manufacturer Part Number (MPN): 76326
- UPC: 611760763267
- Sizing Diameter: .326 in
- Surface Treatment: Titanium Nitride (TiN) coated
- Base Material: Heat-treated steel
- Surface Hardness: Rc 60-62
- Dimensions: 1/2 in O.D. x 3/8 in long
- Compatibility: All Redding bushing-style sizing dies (Type S, Competition)
- Size Increments: .001 in
- Country of Origin: United States
What’s Included
- One Redding .326 Titanium Nitride neck sizing bushing (76326)
Frequently Asked Questions
Which dies does the Redding .326 titanium nitride bushing fit?
It freely interchanges across all Redding bushing-style sizing dies, including the Type S Full Length, Type S Neck, and Competition bushing dies. The standard 1/2 inch by 3/8 inch size means you can swap it between any compatible Redding die in your kit. Dies are sold separately from the bushing.
How do I know if .326 is the right bushing size for my loads?
Measure the outside neck diameter of a loaded or dummy cartridge with a precision micrometer, then subtract .001 to .002 inches. That subtraction accounts for brass spring-back and gives you proper bullet tension. If that math lands you at .326, this is your bushing.
What's the advantage of the titanium nitride bushing over the plain steel version?
The TiN coating increases the effective surface hardness and makes the bushing slicker, so sizing takes less effort and is gentler on your case necks. Reloaders running high volume tend to prefer it because it resists wear and is less likely to scratch brass. The steel bushings still perform well, but the TiN finish is a nice upgrade for consistency and longevity.
Do I still need to lube case necks when using this bushing?
A light touch of neck lube is still a good habit even with the titanium nitride coating. The TiN surface already reduces friction considerably, but a bit of lube keeps the sizing stroke smooth and helps extend brass life. It's a small step that pays off over many firings.
