Redding 73 Style Steel Neck Sizing Bushing .200 Diameter – 73200

UPC: 611760732003

$20.99

2 in stock

Online inventory may differ from in-store availability.

Fast Shipping

Quick turnaround so you get your gear sooner.

Secure FFL-Friendly Checkout

Trusted checkout with industry-standard protection.

Family-Owned Business

Keeping Traditions Alive Since 1953

Secure Transactions provided with

Description

This is the .200" diameter steel bushing from Redding's 73 series, the part of the system that lets you control exactly how much you size your case necks. Instead of sizing the neck way down and springing it back over an expander, a bushing sizes the outside of the neck right to the number you choose. That means less working of the brass, better concentricity, and neck tension you can actually repeat load after load.

How the .200 Steel Bushing Fits Your Setup

Redding neck sizing bushings all share the same external dimensions, so this one freely interchanges across Redding bushing style neck sizing dies, Type S dies, and Competition dies. The bushing self centers on the case neck as it sizes, which is a big part of why these setups turn out such straight ammo. Nothing is permanently installed, so you can keep a small lineup of bushings on hand and swap sizes as you change brass or chase a tighter group.

Picking the Right Redding 73 Series Bushing Size

The sizing number is the key. Seat a bullet in the brass you plan to load, measure the outside diameter of that loaded neck with a caliper or micrometer, then subtract about .001" to .002" to land on your bushing. That small amount accounts for brass springback and gives you a grip that holds the bullet without overworking the neck. The .200" size covers the smaller end of the lineup, which runs in .001" increments from .185" through .368" to handle calibers from .17 up through .338. The last three digits of the part number (73200) tell you the exact diameter, so there's no guessing at the bench.

Built From Heat Treated Steel

Redding makes these from heat treated steel with the sizing diameters hand polished to a surface hardness of Rc 60-62. That hard, slick finish is what keeps sizing effort down and gives the bushing a long working life. It's a small part that does a big job, and it's the kind of detail precision reloaders count on when they want their ammo to come out the same every time.

Key Specifications

  • Diameter: .200 inch
  • Material: Heat treated steel
  • Surface Hardness: Rc 60-62
  • Finish: Hand polished sizing diameter
  • External Dimensions: 1/2" O.D. x 3/8" long
  • Size Increments: .001 inch
  • Full Size Range: .185" through .368"
  • Compatibility: Redding bushing style neck sizing, Type S, and Competition dies
  • Quantity: 1 bushing
  • Manufacturer: Redding
  • Manufacturer Part Number: 73200
  • UPC: 611760732003

What’s Included

  • One Redding 73 style .200 diameter steel neck sizing bushing

Frequently Asked Questions

Which dies does the Redding .200 steel bushing fit?

It fits all Redding bushing style neck sizing dies, Type S dies, and Competition neck sizing dies. Every Redding bushing shares the same outside dimensions, so they freely interchange across those die families. The die itself is sold separately, since Redding ships those dies without a bushing installed.

How do I know if I need the .200 size?

Seat a bullet in the brass you load, measure the outside diameter of the loaded neck with a caliper or micrometer, then subtract roughly .001" to .002". That final number is your bushing size. The .200 bushing is meant for loaded neck diameters right around .201" to .202", which puts it in the smaller caliber range.

What's the difference between the steel bushing and the titanium nitride version?

Both share the same dimensions and interchange in the same dies. The titanium nitride bushings add a surface coating that bumps up hardness and cuts sizing friction a bit more, which some folks prefer with harder brass. The plain heat treated steel version here is the standard choice and works great for most loading.

Does a bushing die bump the case shoulder?

A dedicated neck sizing bushing die only sizes the neck and does not bump the shoulder. If you want to size the body and bump the shoulder in the same pass, that's a job for a Type S Full Length bushing die, which uses this very same bushing. Match the bushing to whichever Redding die you're running.
