Description
Lantac built the Dragon Keymount to do two jobs at once: crush recoil on your AR and serve as a ready-to-go home for a Dead Air KEYMO suppressor. It runs the same Short Energy Pulse gas system that put the Dragon name on the map, shortening the recoil impulse so the energy from repeating shots doesn't overlap and pull you off target. On a 5.56 or .223 rifle, the result is a flat, planted feel that makes fast follow-ups easy and keeps your dot in the glass. Reviewers consistently point out how well it kills muzzle climb, with the rifle staying remarkably level even during rapid strings.
What Sets the Dragon Keymount Apart
The big draw here is the licensed Dead Air mount interface machined right into the brake. That means you can thread on the full range of Dead Air Sandman KEYMO cans without buying a separate mount, and because the design is officially licensed, your suppressor warranty stays intact. It's a clean way to bounce between running your rifle bare and running it suppressed without ever swapping muzzle devices.
Built to Take a Beating
Each Dragon is precision cut on Swiss lathes from AISI 4140 steel, hardened to roughly 48-52 Rockwell C, then finished in a QPQ black nitride treatment that fights corrosion and adds real longevity. It's full-auto rated, so it holds up to hard, high-round-count use. The brake weighs in around 4 ounces and measures about 2.76 inches long with 1/2-28 right-hand threads, the standard pitch on most 5.56 and .223 barrels.
Worth knowing before you buy: like every effective brake, the Dragon trades some noise and side concussion for that recoil reduction. Folks standing next to you at the line will feel it, and it isn't a flash hider. If flat shooting and suppressor readiness are what you're after, though, this is one of the most respected brakes in the game. Lantac suggests using Rocksett thread locker for a semi-permanent install.
Key Specifications
- Manufacturer: Lantac USA
- Model: Dragon (Dead Air KEYMO Mount)
- Manufacturer Part Number: DGN556B-DA
- UPC: 711841794071
- Product Type: Muzzle Brake
- Caliber: .223 Rem / 5.56x45mm NATO
- Thread Pitch: 1/2-28 UNEF Right-Hand
- Material: AISI 4140 Steel, Hardened 48-52 Rc
- Finish: Black Nitride QPQ
- Overall Length: 2.760 in
- Body Diameter: 0.824 in
- Mount Diameter: 1.080 in
- Weight: 4 oz
- Suppressor Mount: Licensed Dead Air Sandman KEYMO
- Country of Origin: USA
What’s Included
- Lantac Dragon Keymount muzzle brake
- Timing shim set
Frequently Asked Questions
What suppressors work with the Dragon Keymount?
It uses a fully licensed Dead Air KEYMO mount interface, so it accepts the full range of Dead Air Sandman KEYMO silencers, including the Sandman-S, Sandman-K, and Sandman-L. Because the mount is officially licensed from Dead Air, mounting a compatible can won't affect your suppressor warranty. The suppressor is sold separately and not included with the brake.
Is the Lantac Dragon Keymount loud?
Yes, like all effective muzzle brakes it redirects gas to the sides, which increases sound and side concussion compared to a bare muzzle or flash hider. Shooters standing next to you will feel it more than you do behind the gun. That extra blast is the tradeoff for the excellent recoil and muzzle rise reduction the Dragon is known for.
Will this fit my .223 or 5.56 AR-15?
It's threaded 1/2-28 right-hand, which is the standard thread pitch on the vast majority of .223 and 5.56 AR-15 barrels. It's designed for AR-15, M16, and M4 pattern rifles and is full-auto rated. Just confirm your barrel's thread pitch and that you have enough barrel length and clearance for the roughly 2.76-inch device.
Does the Dragon Keymount come with a crush washer?
This KEYMO version ships with a timing shim set rather than a crush washer, which lets you properly index and time the brake during installation. Lantac recommends using Rocksett semi-permanent thread locker to secure it, which is sold separately. Following the shim and thread locker method gives you a solid, correctly aligned install.







Reviews
There are no reviews yet.
