Description
If you're running a Hornady Lock-N-Load Automatic Case Feeder, the feed plate is the piece that does the heavy lifting of orienting and dropping your cases, and this one is sized specifically for small rifle brass. The plate that ships with the feeder isn't a one-size-fits-all deal, so having the right diameter plate on hand is what keeps your cases dropping smoothly instead of jamming up the works. This is the small rifle plate, item number 095314, and it covers a solid range of popular cartridges including 223 Rem, 22 Hornet, 222 Remington, 218 Bee, 17 Remington, 30 Carbine, and 7.62x39mm.
What the Small Rifle Plate Handles on Your Lock-N-Load Feeder
The plate is molded from tough black plastic and seats onto the motor drive shaft with two slots on the bottom that engage the drive pawls. Because the small rifle plate is matched to brass with the right case head diameter, it feeds those slimmer rifle cartridges reliably rather than fighting the hopper. If Hornady makes a standard shell plate for the cartridge, odds are good it will run through the feeder with the correct plate installed.
Swapping the 095314 Plate During a Caliber Change
Changeovers are one of the nicer parts of this system. To swap plates you pull straight up on the feed wheel to lift it off the motor shaft, then set the new plate down and rotate it until the pawls lock into the slots. The whole process takes a couple of minutes, and most folks changing cartridges on the Lock-N-Load feeder report full changeovers landing in the five minute range once you've got the right plate, drop tube, and V-block sorted out.
Keep in mind the plates are sold separately from the case feeder itself, so it's smart to pick up the plate that matches the brass you load most. For anyone loading high volumes of 223 or similar small rifle rounds, this plate keeps the hopper doing the tedious work while you stay focused on running the press. It's backed by Hornady's lifetime warranty, which is a nice bit of reassurance on a working part that sees a lot of cycles.
Key Specifications
- Manufacturer: Hornady
- Manufacturer Part Number: 095314
- UPC: 090255953145
- Plate Size: Small Rifle
- Caliber/Gauge: 223 Rem / 22 Hornet
- Compatible Cartridges: 223 Rem, 22 Hornet, 222 Rem, 218 Bee, 17 Rem, 30 Carbine, 7.62x39mm and similar
- Material: Black molded plastic
- Fits: Hornady Lock-N-Load Automatic Case Feeder
- Warranty: Hornady No-Risk Lifetime Warranty
- Made In: USA
- Shipping Weight: 1.61 lbs
What’s Included
- Hornady 095314 Lock-N-Load Small Rifle Case Feeder Plate (1)
Frequently Asked Questions
What cartridges does the 095314 small rifle plate feed?
This plate is built for small rifle brass and covers popular cartridges like 223 Rem, 22 Hornet, 222 Remington, 218 Bee, 17 Remington, 30 Carbine, and 7.62x39mm. As a general rule, if Hornady makes a standard shell plate for the cartridge, it will feed through the hopper with the correct plate installed. For larger rifle brass you'll want the large rifle feeder plate instead.
Will this plate work with my Lock-N-Load Automatic Case Feeder?
Yes. The small rifle plate is designed to work with the Hornady Lock-N-Load Automatic Case Feeder. The case feeder itself bolts to Lock-N-Load AP presses with serial numbers 7000 and higher, and Hornady offers a sub-plate conversion kit for earlier presses.
Does the case feeder come with this plate?
No. The Lock-N-Load Case Feeder is sold with everything you need to run it except the feeder plates, which are purchased separately. That lets you buy only the plate sizes that match the brass you load, so picking up the small rifle plate is the move if you're loading cartridges like 223 Rem.
How hard is it to swap feeder plates when changing calibers?
It's quick. You pull straight up on the feed wheel to lift the old plate off the motor shaft, then set the new plate on and rotate it until the drive pawls engage the two slots underneath. A full cartridge changeover on the feeder, including the plate, drop tube, and V-block, typically runs around five minutes.





Reviews
There are no reviews yet.
