Description
The .338 ARC is Hornady's big-bore answer for folks who want serious terminal punch out of a standard AR-15, and Faxon built this Gunner barrel to make the most of it. At 14.5 inches with a pistol-length gas system, it keeps the whole package short and handy, which is exactly what you want when you're running a can or working through brush. The cartridge shines with heavy subsonic loads around 307 grains that push roughly 1.5 times the energy of subsonic 300 Blackout, and it still cycles supersonic 175-grain rounds from the same barrel with no gas changes needed.
What the Gunner Profile Brings to the Table
The Gunner contour is Faxon's mix of the Government and Pencil profiles. You get most of the toughness of a heavier barrel without the front-heavy feel, and the balance sits back toward your shoulder so the rifle points fast and doesn't wear you out over a long day. For a hunting rifle or a truck gun that lives on a sling, that trade-off makes a real difference.
Build Quality on This 338 ARC Barrel
Faxon machines these in-house in Cincinnati from 416-R stainless steel, then finishes them in black nitride for hardness and corrosion resistance. Each barrel is stress relieved, air-gauge tested, magnetic particle inspected, and headspace checked with PTG gauges. The 1:8 twist stabilizes the wide spread of .338 bullet weights this cartridge uses, and the muzzle wears an 11-degree target crown for clean, consistent accuracy.
Fitting It to Your AR-15
This is a pistol-length gas barrel with a .750 gas block journal, an M4 barrel extension, and 5/8×24 muzzle threads that play nice with common .30-caliber muzzle devices and suppressors. It drops into a standard AR-15 build using a 6.5 Grendel bolt and standard AR magazines. Worth knowing up front: some builders find that lightly adjusting the upper's feed ramps helps feeding, especially with the heavy Sub-X subsonic loads, and Faxon recommends pairing it with a .338 ARC-optimized upper for the smoothest results.
Key Specifications
- Manufacturer: Faxon Firearms
- Manufacturer Part Number: 15B338A8P145NGQ-5R-NP3
- UPC: 816341028852
- Caliber: .338 ARC
- Barrel Length: 14.5"
- Profile: Gunner
- Material: 416-R Stainless Steel
- Finish: Black Nitride
- Twist Rate: 1:8
- Rifling: 5R, Button Rifled
- Gas System: Pistol-Length
- Gas Block Journal: .750"
- Muzzle Threads: 5/8×24
- Muzzle Crown: 11-Degree Target Crown
- Barrel Extension: M4
- Platform Compatibility: AR-15
What’s Included
- Faxon Gunner 14.5in .338 ARC barrel
Frequently Asked Questions
Will this Faxon 338 ARC barrel run both subsonic and supersonic ammo?
Yes. The .338 ARC was designed to cycle heavy subsonic loads and lighter supersonic loads from the same barrel with no adjustments to the rifle. The 1:8 twist stabilizes the full range of bullet weights, from around 175-grain supersonic to 300-plus-grain subsonic.
What bolt and magazines does the Faxon Gunner 338 ARC barrel use?
The .338 ARC is based on a necked-up 6mm ARC case and uses a 6.5 Grendel bolt face. It also feeds from standard AR-15 magazines, so you can build on a normal lower without special mags.
Is the 14.5-inch Gunner barrel a good choice for a suppressed setup?
It's one of the main reasons this cartridge exists. The 5/8×24 muzzle threads accept common .30-caliber muzzle devices and suppressors, and the short 14.5-inch pistol-length configuration keeps the rifle compact and controllable when you hang a can off the end. Subsonic .338 ARC is notably quiet through a suppressor thanks to its low-flash powders and heavy projectiles.
Do I need a special upper for this Faxon 338 ARC barrel?
It fits standard AR-15 uppers, but Faxon recommends a .338 ARC-optimized upper for the most consistent feeding. Some builders find that lightly tuning the feed ramps improves reliability, particularly with the heavier Hornady Sub-X subsonic loads.
