Description
The Redding Competition Seating Die for the 6.5×55 Swedish Mauser is about as refined as bullet seating gets. This is the micrometer-topped seater that match reloaders reach for when runout and repeatability matter. Instead of the bullet floating freely into the case mouth like a standard seater, this die uses an internal sliding sleeve that captures and aligns the entire cartridge before the seating stem makes contact. The result is straighter ammo with less runout, which translates directly to tighter groups downrange.
How the 6.5×55 Swede Competition Seater Lines Things Up
The heart of this die is its precision sliding chamber sleeve. It's cut with a one-piece reamer to SAAMI chamber dimensions, so the case is held and centered exactly as it enters the die. As you raise the ram, a spring system pushes the case and bullet up to meet the seating stem, keeping everything from shifting during the stroke. The seating stem itself is precision ground to match 6.5mm bullet diameter and rides independently of the micrometer, so alignment never gets muddied by the depth adjustment. Reloaders often describe the fit as so tight the stem seems to float on a column of air.
Dialing In Seating Depth
The micrometer head is calibrated in .001" increments and runs .050" per full revolution. It's click-free and infinitely adjustable, so you can fine tune to exactly where your rifle likes the bullet. The zero-set feature lets you reset the micrometer to your favorite load, which is a real time saver during load development when you're chasing the sweet spot or switching between bullet shapes in the same rifle.
Good To Know Before You Load
This die handles seating only. It does not crimp, so if your 6.5×55 loads call for a crimp you'll want to add a separate crimp die. Redding also notes this one isn't meant for heavily compressed powder charges, since the precision-ground stem is built more like a measuring instrument than a press tool. Treat it accordingly and it'll produce beautifully concentric ammo for a very long time. Made in the USA.
Key Specifications
- Manufacturer: Redding
- Manufacturer Part Number: 55132
- UPC: 611760551321
- Cartridge: 6.5x55mm Swedish Mauser
- Die Type: Competition Bullet Seating Die
- Number of Dies: 1
- Adjustment: Micrometer, .001" increments (.050" per revolution)
- Adjustment Feel: Click-free, infinitely adjustable with zero-set feature
- Alignment: Precision ground sliding chamber sleeve with floating seating stem
- Thread: 7/8"-14
- Crimp: No crimp function (seating only)
- Country of Origin: Made in USA
What’s Included
- One Redding Competition Seating Die for 6.5×55 Swedish Mauser
- Precision ground sliding chamber sleeve
- Micrometer adjustment head with precision ground bullet seating stem
- 7/8"-14 lock ring
Frequently Asked Questions
Does the Redding Competition Seating Die crimp the bullet?
No, this die seats the bullet only and does not apply a crimp. If your 6.5×55 loads need a crimp, you'll want to pick up a separate crimp die, such as a Redding Taper or Profile Crimp Die. For most precision 6.5×55 bolt-gun loads, a crimp isn't necessary at all.
Will this die work in my reloading press?
Yes. It uses industry-standard 7/8"-14 threads, so it fits virtually any single-stage or turret press built to that spec. When setting it up, leave a slight gap between the shellholder and the die body so the internal sliding sleeve can function properly.
Can I use the Competition Seating Die with compressed powder charges?
Redding recommends against it. The seating stem is precision ground to match bullet diameter, which makes its walls relatively thin, and heavy compressed loads can stress that stem. For compressed charges, a standard seating die is the better choice.
What makes this seater more accurate than a standard seating die?
The internal sliding sleeve captures and aligns the entire cartridge case before the bullet seating begins, and the seating stem moves independently of the micrometer. That combination holds everything concentric and minimizes bullet runout, which helps your handloads shoot tighter. It's a big reason match reloaders favor this design.
