Redding 30-30 Winchester Full Length 2-Die Set 80146

UPC: 611760801464

$57.99

2 in stock

Online inventory may differ from in-store availability.

Fast Shipping

Quick turnaround so you get your gear sooner.

Secure FFL-Friendly Checkout

Trusted checkout with industry-standard protection.

Family-Owned Business

Keeping Traditions Alive Since 1953

Secure Transactions provided with

Description

The .30-30 Winchester has been feeding lever guns for well over a century, and if you're loading for a Marlin, Winchester, or Henry, a quality die set makes all the difference. Redding's 80146 Full Length 2-Die Set is about as proven as it gets, built around the same standard that reloaders have leaned on for hunting and target work for decades. You get precise, repeatable results without any fuss, which is exactly what you want when you're cranking out a batch of brass for deer season.

What the 30-30 Full Length Die Set Does

This is a two-die setup made for bottleneck cases. The full length sizing die resizes the entire case body back to standard chamber dimensions and bumps the shoulder as needed, so your reloads drop into any standard chamber with no drama. It includes a decapping rod assembly with a neck expander button and a decapping pin to knock out the spent primer in the same stroke. The seating die handles the second half of the job with a bullet guide, a proper seating plug, and a built-in crimping ring, so you can roll a crimp into that cannelure for tube-fed lever actions if you want it.

Redding Build Quality on the 80146 Die Set

Redding has been grinding out dies since 1946, and the reputation holds up. These are machined from steel with the kind of fit and finish that makes threading them into your press feel right. The dies use the industry-standard 7/8-14 thread, so they'll work in just about any single stage or turret press you've got on the bench. Each set ships ready to run after a quick setup and adjustment.

A couple of things worth knowing before you order: the shellholder is not included, and for the .30-30 you'll want a #2 shellholder. Spare decapping pins and an Allen wrench for the lock rings come along for the ride, and the whole set tucks into a storage box when you're done.

Key Specifications

  • Manufacturer: Redding
  • Manufacturer Part Number: 80146
  • UPC: 611760801464
  • Caliber: .30-30 Winchester (30 WCF)
  • Set Type: Full Length 2-Die Set
  • Dies Included: Full length sizing die, seating die
  • Material: Steel
  • Thread Size: 7/8-14
  • Bullet Diameter: 0.308
  • Shellholder: #2 (sold separately)
  • Country of Origin: United States
  • Shipping Weight: 1.2813 lbs

What’s Included

  • Full length sizing die with decapping rod assembly, neck expander button, and decapping pin
  • Standard bullet seating die with bullet guide, seating plug, and built-in crimping ring
  • Spare decapping pin
  • Allen wrench for lock rings
  • Storage box
  • Instructions

Frequently Asked Questions

Does the Redding 30-30 die set include a shellholder?

No, the shellholder is sold separately. For the .30-30 Winchester you'll need a #2 shellholder. It's a quick, inexpensive add that you may already have on hand if you load similar cartridges.

Can this die set crimp .30-30 ammo for a lever action?

Yes. The seating die has a built-in crimping ring, so you can apply a crimp into the bullet's cannelure during seating. That's important for tube-fed lever guns where recoil can push bullets deeper in the magazine if they aren't crimped.

Will the Redding 80146 dies fit my press?

They use the standard 7/8-14 thread, so they'll thread into virtually any common single stage or turret reloading press. If your press takes standard dies, you're good to go.

What's the difference between this full length set and a neck sizing set?

The full length die resizes the entire case body and bumps the shoulder back, so your reloads chamber reliably in any standard .30-30 firearm. That makes it the practical choice for lever guns and for brass shared between rifles, where full sizing keeps everything feeding smoothly.

Additional information

UPC

611760801464

Manufacturer

Manufacturer Part Number

80146

Shipping Weight

1.2813
